• Number of axles: 1
• Tyre size: 185 R 14 C
• Overall length: 7.568 mm
• Body length: 6.404 mm
• Overall width / internal width: 2.500 / 2.367 mm
• Overall height / Internal headroom: 2.637 / 1.950 mm
• Maximum technically permissible laden mass: 1,600 kg
• Mass in running order: 1.456 kg
• Payload: 144 kg
• Technically possible load capacity increase up to: 2.000 kg
• Payload at maximum payload: 506 kg
• Body wall thickness (floor/roof/walls): 39/31/31 mm
• Perimeter of the awning: 10.160 mm
• Edging (straight edge): 4.448
• Number of beds (adults/children): 4
• Number of 230 V power sockets (single/dual): 5 / 3

Doors and access equipment:

• Single entrance door, extra wide, with three-point locking, window, waste bin, compartments and pleated insect screen in the door frame, design depending on model

Interior equipment:

• Single column lifting table
• Heated clothes rack in entrance area
• Wall cabinets with plenty of storage space and soft-closing doors
• Cupboard with internal lighting
• Compartment under the seat
• TV cabinet with illuminated cabinet, Visby oak / white gloss, Cara

Kitchen:

• Refrigerator DOMETIC, 133 l, 10 series, including 12 l freezer compartment, with double hinges, absorption technology
• Stainless steel hob and sink with 3-burner hob, electric ignition and split glass lid
• Cutlery insert
• Spice racks
• Towel holder
• Kitchen backrest with fully integrated blackout blind and insect screen, kitchen light, 230 V power sockets and USB charging socket
• Kitchen lighting and separate electrical sockets
• Large drawers, fully retractable, with soft-closing and sliding lock mechanisms

Bedrooms and beds:

• Double bed
• Bed lifter with cross frames and gas spring, for double and twin beds
• Spring mattresses for single, double and twin beds

Bathroom:

• Rear washbasin with separate shower cubicle, design depending on model
• Swivel toilet THETFORD
• Waste water tank, 23,5 l, rolling
• Fresh water tank, 47 litres
• Submersible pump
• Bed size, double bed (length x width): 1.985 x 1.385 / 1.150 mm
• Bed size, converted into a seating bed (length x width): 2.233 x 1.600 / 1.300 mm

External equipment and security:

• Integrated third brake light
• Stabiliser attachment KNOTT
• KNOTT ANS with automatic adjustment of the transition brake (x2)
• Rear fog lamp
• Hub wheel
• Attachment cover
• One-key locking system
• Wheel shock absorbers
• Tyre repair kit
• High-resistance supports
• Load indicator on the connecting wheel
• Licence to drive up to 100 km/h
• Steel wheels, silver with wheel caps
• Gripping handle
• Entrance step
• Gas cabinet with space for 2 x 11 kg bottles
• Integrated awning rail
• LED awning lighting
• Wheel arches, thermally insulated
• Front and rear awning rail rain deflector with water drainage system
• Wheel arch protector with rubber edge for draught protection
• Storage room door MAXI, THETFORD with central locking, 1000 x 300 mm, lockable
• Smoke alarm

Heating and ventilation:

• Winter vents in seating areas, cupboards and beds
• TRUMA Combi 6 heating system including 10 l hot water system and frost control valve

Gas and electricity system:

• Gas regulator with overpressure protection (DIN EN 12 864) and hose line
• Gas control taps in kitchen cupboards
• Control panel for lighting system and tank display
• Light switch for children
• Electronically controlled 12 V / 350 VA power supply
• Earthing circuit breaker
• External awning socket including 230 V output, satellite/TV connection
• Antenna socket with coaxial cable in a residential area
• JAEGER passenger vehicle connector, 13 poles

External equipment and security:

• Integrated third brake light
• Stabiliser attachment KNOTT
• KNOTT ANS with automatic adjustment of the transition brake (x2)
• Rear fog lamp
• Hub wheel
• Attachment cover
• One-key locking system
• Wheel shock absorbers
• Tyre repair kit
• High-resistance supports
• Load indicator on the connecting wheel
• Licence to drive up to 100 km/h
• Steel wheels, silver with wheel caps
• Gripping handle
• Entrance step
• Gas cabinet with space for 2 x 11 kg bottles
• Integrated awning rail
• LED awning lighting
• Wheel arches, thermally insulated
• Front and rear awning rail rain deflector with water drainage system
• Wheel arch protector with rubber edge for draught protection
• Storage room door MAXI, THETFORD with central locking, 1000 x 300 mm, lockable
• Smoke alarm

Windows and ventilation:

• Cartridge with pleated blinds and insect screen for all windows (except bathroom)
• Panoramic front window with integrated blackout blinds and insect screen
• Casement window, opening, double-glazed and tinted
• Roof window DOMETIC SEITZ, Midi-Heki 700 x 500 mm, with pleated blinds and insect screen in living area
• Skylight DOMETIC SEITZ, Mini-Heki 400 x 400 mm, with pleated blinds and insect screen in sleeping area
• Skylight DOMETIC SEITZ, Mini-Heki 400 x 400 mm, with pleated blinds and fly screen in washroom
• Casement window with frosted glass appearance, can be opened

Lighting:

• Ambient lighting, design depends on model
• Reading lights in the seat
• Reading lights in the sleeping area

Technology:

• HOBBY CONNECT, control of in-vehicle technologies via the HOBBY control panel and Bluetooth via an app
