• Number of axles: 2
• Tyre size: 165 R 13 C
• Overall length: 9.046 mm
• Body length: 7,868 mm
• Overall width / internal width: 2.500 / 2.367 mm
• Overall height / Interior height: 2.639 / 1.950 mm
• Maximum technically permissible laden mass: 2,200 kg
• Mass in running order: 1,855 kg
• Payload: 345 kg
• Technically possible load capacity increase up to: 2,500 kg
• Payload at maximum payload: 645 kg
• Load reduction up to 2 000 kg is technically possible
• Body wall thickness (floor/roof/walls): 41/31/31 mm
• Perimeter of the awning: 11.640 mm
• Edging (straight edge): 5.872
• Number of beds (adults/children): 4
• Bed size, double bed (length x width): 1,990 x 1,395 mm
• Bed size, conversion of seating bed (length x width): 2.233 x 2.000 / 1.600 mm
• Number of 230 V power sockets (single/dual): 6 / 2

External equipment and security:

• Integrated third brake light
• Stabiliser attachment KNOTT
• KNOTT ANS with automatic adjustment of the transition brake (x2)
• Rear fog lamp
• Hub wheel
• Attachment cover
• One-key locking system
• Wheel shock absorbers
• High-resistance supports
• Licensed for speeds up to 100 km/h
• Steel wheels, silver with wheel caps

Doors and access equipment:

• Single entrance door, extra wide, with three-point locking, window, waste bin, compartments and pleated insect screen in the door frame, design depending on model
• Rankena
• Entrance step

Storage solutions:

• Gas cabinet, holds 2 x 11 kg bottles
• Integrated awning rail
• LED awning lighting
• Wheel arches, thermally insulated
• Front and rear awning rail rain deflector with water drainage
• Wheel arch protector with rubber edge for draught protection
• Locker door, THETFORD with central locking, 752 x 310 mm, lockable
• Winter vents in seating, lockers and beds
• Single column lifting table
• Heated clothes rack in entrance area
• Wall cabinets with plenty of storage space and soft-closing doors
• Cupboard with internal lighting
• Compartment under the seat
• TV cabinet with illuminated cabinet, Visby oak / white gloss

Kitchen

• Refrigerator DOMETIC, 133 l, 10 series, including 12 l freezer compartment, with double hinges, absorption technology
• Stainless steel hob and sink with 3-burner hob, electric ignition and split glass lid
• Cutlery insert
• Corner base cabinet with swivel pull-out drawer
• Spice racks
• Towel holder
• Kitchen backrest with integrated blackout blind and insect screen, kitchen light, 230 V power sockets and USB charging socket
• Kitchen lighting and separate electrical sockets
• Large drawers, fully extendable, with soft-closing and sliding locks
• Storage basket with pull-out drawer

Bedrooms and beds

• "Queen size bed
• Bed lift with slats and gas spring for double and twin beds
• Cold foam mattress, with comfort zones and slatted bed base, for double beds and queen size beds
• Bed linen

Bathroom

• Rear washbasin with separate shower cubicle, design depending on model
• Swivel toilet THETFORD
• Casement window with frosted glass appearance, can be opened
• Waste water tank, 23,5 l, rolling
• Fresh water tank, 47 litres
• Submersible pump

• Submersible pump

Gas and electricity system:

• Gas regulator with overpressure protection (DIN EN 12 864) and hose line
• Gas control taps in a kitchen cupboard
• Control panel for lighting system and tank display
• Light switch for children
• Electronically controlled 12 V / 350 VA power supply
• Earthing circuit breaker
• External awning socket including 230 V output, satellite/TV connection
• Antenna socket with coaxial cable in a residential area
• JAEGER passenger vehicle connector, 13 poles
• Smoke alarm

Lighting:

• Reading lights in the seat
• Reading lights in the sleeping area

Heating and ventilation:

• TRUMA Combi 6 heating system including 10 l hot water system and frost control valve

Windows and ventilation:

• Combination cassette with pleated blinds and insect screen for all windows (except bathroom)
• Panoramic windscreen with fully integrated blackout blinds and insect screen
• Casement window that can be opened, with double glazing and tinted glass
• Roof window DOMETIC SEITZ, Midi-Heki 700 x 500 mm, with pleated blinds and fly screen in living area
• Skylight DOMETIC SEITZ, Mini-Heki 400 x 400 mm, with pleated blinds and insect screen in sleeping area

Technology:

• HOBBY CONNECT, control of in-vehicle technologies via the HOBBY control panel and Bluetooth via an app
